Motor Modules Booksize
6.4 Motor Modules with cold plate
Booksize Power Units
468 Manual, (GH2), 04/2014, 6SL3097-4AC00-0BP6
Characteristics for Motor Modules Booksize with 300% overload
Rated duty cycles Motor Modules Booksize with 300% overload
Figure 6-91 Peak current duty cycle with initial load (300% overload)
Figure 6-92 Duty cycle with initial load
Figure 6-93 Duty cycle without initial load
Figure 6-94 S6 duty cycle with initial load for a duty cycle duration of 600 s
