6.4 Motor Modules with cold plate
Booksize Power Units
464 Manual, (GH2), 04/2014, 6SL3097-4AC00-0BP6
6.4.8
Technical data for Motor Modules Booksize with 300% overload
6.4.8.1
Single Motor Modules (300% overload)
Table 6- 45 Technical data Single Motor Modules (3 to 18 A) with 300% overload
Cold plate
6SL3126-
1TE13-0AA4
1TE15-0AA4
1TE21-0AA4
1TE21-8AA4
Output current
Rated current (I
n
)
Base-load current (I
H
)
Intermittent duty current (I
S6
) 40%
Peak current (I
max
)
A
ACrms
A
A
ACrms
A
ACrms
3
2,6
3,5
9
5
4,3
6
15
9
7,7
10
27
18
15,3
24
54
Output voltage
V
ACrms
0 … 0.717 x DC-link voltage
DC-link current I
d max
A
DC
3,6
6
11
22
DC-link voltage
(up to 2000 m above sea level)
V
DC
510 … 720
DC-link capacitance
μF
110
110
110
220
Overvoltage trip
Undervoltage trip
1)
V
DC
V
DC
820 ± 2 %
380
Electronics power supply
V
DC
24 (20,4 … 28,8)
Electronics current drawn
at 24 VDC
A
DC
0,65
Current carrying capacity
DC-link busbars
Reinforced DC-link busbars
24 VDC busbars
A
DC
A
DC
A
DC
100
150
20
Unit rating
2)
Based on I
n
(600 VDC; 4 kHz)
Based on I
H
kW
kW
1,6
1,1
2,7
2,3
4,8
4,1
9,7
8,2
Total power loss
(including electronics losses, see Power
loss tables (Page 781))
W 45,5 70,6 95,6 180,6
Max. pulse frequency
without derating
with derating
kHz
kHz
4
16
Max. ambient temperature
without derating
with derating
° C
° C
40
55
Max. permissible heat sink temperature
° C
70
70
70
70
Weight
kg
4,2
4,2
4,5
4,5
1)
Default for 400 V line systems; undervoltage trip threshold can be reduced by up to 80 V and is adjusted to the
parameterized rated voltage
2)
Rated power of a typical standard induction motor at 400 V 3 AC.
