Booksize Power Units
Manual, (GH2), 04/2014, 6SL3097-4AC00-0BP6
345
Line Modules Booksize Compact
Smart Line Modules Booksize Compact
5.1.1
The Smart Line Module booksize compact is a non-regulated infeed/regenerative feedback
unit. The Smart Line Module supplies the Motor Module with a non-regulated DC voltage at
the DC output. In the infeed mode the Smart Line Module exhibits the typical current and
voltage waveforms of a 6-pulse diode rectifier bridge.
In feedback mode, the current waveform is square waved. The regenerative feedback can
be deactivated by means of parameters.
A line contactor can be installed on the line side if the system has to be electrically isolated
from the line supply.
The Smart Line Module in booksize compact format can be used with cooling types "internal
air cooling" or "cold plate". The cooling type is selected by parameter (see the SINAMICS
S120/S150 List Manual).
Smart Line Modules are suitable for direct operation in TN, IT, and TT systems. The Line
Modules have an integrated overvoltage protection function.
Safety instructions for Smart Line Modules Booksize Compact
Danger to life if the fundamental safety instructions and remaining risks are not carefully
observed
If the fundamental safety instructions and remaining risks in Chapter 1 (Page 25) are not
observed, accidents involving severe injuries or death may occur.
• Adhere to the fundamental safety instructions.
• When assessing the risk, take into account residual risks.
