Motor Modules Booksize
6.3 Motor Module with external air cooling
Booksize Power Units
Manual, (GH2), 04/2014, 6SL3097-4AC00-0BP6
427
Characteristics
Rated duty cycles Motor Modules Booksize
Figure 6-49 Duty cycle with initial load (for servo drives)
Figure 6-50 Duty cycle without initial load (for servo drives)
Figure 6-51 S6 duty cycle with initial load with a duty cycle duration of 600 s (for servo drives)
Figure 6-52 S6 duty cycle with initial load with a duty cycle duration of 60 s (for servo drives)
