6.2 Motor Modules with internal air cooling
Booksize Power Units
Manual, (GH2), 04/2014, 6SL3097-4AC00-0BP6
395
6.2.8.2
Double Motor Modules (300% overload)
Table 6- 15 Technical data Double Motor Modules Booksize (2 x 3 to 2 x 9 A) with 300% overload
Internal air cooling
6SL3120-
2TE13-0AA4
2TE15-0AA4
2TE21-0AA4
Output current
Rated current (l
n
)
Base-load current (I
H
)
Intermittent duty current (I
s6
) 40%
Peak current (l
max
)
A
ACrms
A
A
ACrms
A
ACrms
2 x 3
2 x 2.6
2 x 3.5
2 x 9
2 x 5
2 x 4.3
2 x 6
2 x 15
2 x 9
2 x 7.7
2 x 10
2 x 27
Output voltage
V
ACrms
0 … 0.717 x DC-link voltage
DC-link current I
d max
A
DC
7,2
12
22
DC-link voltage
(up to 2000 m above sea level)
V
DC
510 … 720
DC-link capacitance
μF
220
Overvoltage trip
Undervoltage trip
1)
V
DC
V
DC
820 ± 2 %
380 ± 2 %
Electronics power supply
V
DC
24 (20,4 … 28,8)
Electronics current drawn
at 24 VDC
A
DC
1,15
Current carrying capacity
DC-link busbars
Reinforced DC-link busbars
24 VDC busbars
A
DC
A
DC
A
100
150
20
Unit rating
2)
Based on I
n
(600 VDC; 4 kHz)
Based on I
H
kW
kW
2 x 1.6
2 x 1.4
2 x 2.7
2 x 2.3
2 x 4.8
2 x 4.1
Total power loss
(including electronics losses, see Power loss
tables (Page 781))
W 97,6 132,6 187,6
Max. pulse frequency
without derating
with derating
kHz
kHz
4
16
Max. ambient temperature
without derating
with derating
° C
° C
40
55
Sound pressure level
dB(A)
< 60
Cooling method
Internal fan
Cooling air requirement
m
3
/h
29,6
Max. permissible heat sink temperature
° C
84
78
92
Weight
kg 5,3 5,3 5,5
1)
Default for 400 V line systems; undervoltage trip threshold can be reduced by up to 80 V and is adjusted to the
parameterized rated voltage
2)
Rated power of a typical standard induction motor at 400 V 3 AC.
