4.9 Smart Line Modules with external air cooling
Booksize Power Units
324 Manual, (GH2), 04/2014, 6SL3097-4AC00-0BP6
Note
If the cooling air requirement is not covered by the filtered fan, the components can
not
output their specified power.
The filters with filter fan must be regularly checked for dirt and cleaned if necessary.
Help with the mechanical control cabinet design is available from
:
Siemens AG
Industry Sector, IA DT MC MF - WKC AS
TCCCC (Technical Competence Center Cabinets Chemnitz)
Postfach 1124
09070 Chemnitz, Germany
E-mail: cc.cabinetcooling.aud@siemens.com
4.9.8
Technical data
Table 4- 85 Technical data Smart Line Modules Booksize external air cooling
Internal air cooling
6SL3131–
6AE15–0AAx
6AE21–0AAx
6TE21-6AAx
6TE23-6AAx
6TE25-5AAx
Rated power
kW
5
10
16
36
55
Infeed
Rated power (S1)
1)
S6 operation (40 %)
1)
Peak infeed power
1)
kW (P
n
)
kW (P
s6
)
kW (P
max
)
5
6,5
10
10
13
20
16
21
35
36
47
70
55
71
91
Regenerative feedback
Continuous regenerative
power
Peak regenerative power
kW
kW
5
10
10
20
16
35
36
70
55
91
Supply voltages
Line voltage
Line frequency
Electronics power supply
V
AC
Hz
V
DC
3 AC 380 … 480 ± 10 % (-15 % < 1 min)
47 … 63
24 (20.4 … 28.8)
DC link voltage
Overvoltage trip
Undervoltage trip
2)
V
DC
V
DC
V
DC
510 … 720
820 ± 2 %
360 ± 2 %
Input currents
Rated input current
at AC 400 V
at AC 380 V / AC 480 V
S6 (40 %)
at AC 400 V
Peak current
at AC 400 V
A
AC
A
AC
A
AC
A
AC
8,1
8,6 / 6,7
10,6
15,7
16,2
17 / 12,8
21,1
31,2
27,5
29 / 24,5
35
57,5
59
62 / 51
76
112
90
94 / 77
106
130
