Motor Modules Booksize
6.2 Motor Modules with internal air cooling
Booksize Power Units
368 Manual, (GH2), 04/2014, 6SL3097-4AC00-0BP6
Motor Modules with internal air cooling
6.2.1
A Motor Module is a power unit (inverter) that provides the power for the connected motors.
Power is supplied by the DC link of the drive unit. A Motor Module must be connected to a
Control Unit via DRIVE-CLiQ. The open-loop and closed-loop control functions for the Motor
Module are stored in the Control Unit.
One motor can be connected to Single Motor Modules and 2 motors can be connected to
Double Motor Modules.
Danger to life if the fundamental safety instructions and remaining risks are not carefully
observed
If the fundamental safety instructions and remaining risks in Chapter 1 (Page 25) are not
observed, accidents involving severe injuries or death may occur.
• Adhere to the fundamental safety instructions.
• When assessing the risk, take into account residual risks.
