Line connection and line-side power components
3.7 Line filters
Booksize Power Units
Manual, (GH2), 04/2014, 6SL3097-4AC00-0BP6
69
Figure 3-10 Interface overview, Wideband Line Filter for Active Line Modules (example: 16 kW)
Damage caused by overheating as a result of an inadmissible mounting position
If the component is not operated in a vertical position with the line supply terminals at the
bottom, then the component can be damaged.
• Only operate the components in a vertical position with the line terminals at the bottom.
