Siemens 6SL3120-2TE21-0AA3 User Manual

Motor Modules Booksize
6.2 Motor Modules with internal air cooling
Booksize Power Units
386 Manual, (GH2), 04/2014, 6SL3097-4AC00-0BP6
6.2.7
Technical data
6.2.7.1
Single Motor Modules
Table 6- 11 Technical data Single Motor Modules Booksize (3 to 30 A)
Internal air cooling
6SL3120–
1TE13-
0AAx
1)
1TE15-
0AAx
1)
1TE21–
0AAx
1)
1TE21–
8AAx
1)
1TE23-
0AAx
Output current
Rated current (l
n
)
Base-load current (I
H
)
Intermittent duty current (I
s6
) 40%
Peak current (l
max
)
A
ACrms
A
A
ACrms
A
ACrms
3
2,6
3,5
6
5
4,3
6
10
9
7,7
10
18
18
15,3
24
36
30
25,5
40
56
Output voltage
V
ACrms
0 … 0.717 x DC-link voltage
DC-link current I
d max
A
DC
3,6
6
11
22
36
DC-link voltage (up to 2000 m above sea level)
V
DC
510 … 720
DC-link capacitance
μF
110
110
110
220
705
Overvoltage trip
Undervoltage trip
2)
V
DC
V
DC
820 ± 2 %
380 ± 2 %
Electronics power supply
V
DC
24 (20,4 … 28,8)
Electronics current drawn
at 24 VDC
A
DC
0,85
0,85
0,85
0,85
0,8
Current carrying capacity
DC-link busbars
Reinforced DC-link busbars
24 VDC busbars
A
DC
A
DC
A
DC
100
150
20
Unit rating
3)
Based on I
n
(600 VDC; 4 kHz)
Based on I
H
kW
kW
1,6
1,4
2,7
2,3
4,8
4,1
9,7
8,2
16
13,7
Total power loss
(including electronics losses, see Power loss
tables (Page 781))
W 50,4 73,4 100,4 185,4 309,2
Max. pulse frequency
without derating
with derating
kHz
kHz
4
16
Max. ambient temperature
without derating
with derating
° C
° C
40
55
Sound pressure level
dB(A)
< 60
< 60
< 60
< 60
< 60
Cooling method
Internal fan
Cooling air requirement
m
3
/h
29,6
29,6
29,6
29,6
56
Max. permissible heat sink temperature
° C
75
75
79
82
85
Weight
kg
5
5
5
5
6,9
1)
Applies only to order numbers with x = 0 .. 3
2)
Default for 400 V line systems; undervoltage trip threshold can be reduced by up to 80 V and is adjusted to the
parameterized rated voltage
3)
Rated power of a typical standard induction motor at 400 V 3 AC.
