Parameter Function Parameter values Unit
49.PNEUM Pneumatics type
Standard pneumatic block Std
Fail in place pneumatic block FIP
Operation with boosters booSt
50.XDIAG Activation of extended diagnostics
Off OFF
Single stage message On1
Two stage message On2
Three stage message On3
51.FSTY Safety position
Parameterized safety setpoint FSVL
Last setpoint FSSP
Open vent valve FSAC
52.FSTI Monitoring period for setting the safety setting 0 ... 100 s
53.FSVL Safety setpoint 0.0 ... 100.0 %
54.STNR Station number 0 ... 126
55.IDENT Device operating mode (ID No.)
Vendor-independent profile ID number 9710
Device-spec. ID number for full function‐
ality
8079
Automatic adaptation by the control sys‐
tem
AdAPT
1)
Setpoint turning points only appear when '9.SFCT = FrEE' is selected.
2)
'Normally closed' means: Operation when a switch is open or Low level
'Normally open' means: Action on switch closed or High level
3)
'Normal' means: High level, no fault message
'Inverted' means: Low level, no fault message
4)
'+' means: Logical OR combination
8.2.3 Overview of advanced diagnostics parameters A to P
Introduction
These parameters are used to set the extended diagnostics functions of the positioner.
Note
Factory setting
Factory-set parameter values are printed in bold in the following table.
Parameter assignment
8.2 Tabular overview of the parameters
SIPART PS2 with PROFIBUS PA
138 Operating Instructions, 05/2019, A5E00127926-AC
