Byte Bit No. Diagnostics events Hard-coded effect of a diagnostics event
Quality status code DIAGNOSTICS bit
2 0 65 Limit 2 for path integral (100%
strokes) exceeded
Good, maintenance required DIA_MAINTENANCE
1 66 Limit 3 for path integral (100%
strokes) exceeded
Good, maintenance required DIA_MAINTENANCE
2 67 Limit 1 for changes of direction
exceeded
Good, maintenance required DIA_MAINTENANCE
3 68 Limit 2 for changes of direction
exceeded
Good, maintenance required DIA_MAINTENANCE
4 69 Limit 3 for changes of direction
exceeded
Good, maintenance required DIA_MAINTENANCE
5 70 Limit 1 for position average ex‐
ceeded
Good, maintenance required DIA_MAINTENANCE
6 71 Limit 2 for position average ex‐
ceeded
Good, maintenance required DIA_MAINTENANCE
7 72 Limit 3 for position average ex‐
ceeded
Good, maintenance required DIA_MAINTENANCE
3 0 73 PST reference time exceeded
(limit 1)
Good, maintenance required DIA_MAINTENANCE
1 74 PST reference time exceeded
(limit 2)
Good, maintenance required DIA_MAINTENANCE
2 75 PST reference time exceeded
(limit 3)
Good, maintenance required DIA_MAINTENANCE
76 ... 80 Reserved - -
4 0 81 Permissible device tempera‐
ture exceeded (limit 1)
Good, maintenance required DIA_TEMP_ELECTR
1 82 Permissible device tempera‐
ture exceeded (limit 2)
Good, maintenance required DIA_TEMP_ELECTR
2 83 Permissible device tempera‐
ture exceeded (limit 3)
Good, maintenance required DIA_TEMP_ELECTR
3 84 Permissible device tempera‐
ture undershot (limit 1)
Good, maintenance required DIA_TEMP_ELECTR
4 85 Permissible device tempera‐
ture undershot (limit 2)
Good, maintenance required DIA_TEMP_ELECTR
5 86 Permissible device tempera‐
ture undershot (limit 3)
Good, maintenance required DIA_TEMP_ELECTR
6 87 Limit for dead zone monitoring
exceeded
Good, maintenance required DIA_TEMP_ELECTR
88 ... 96 Reserved - -
9.3.3.7 List of diagnostics events with status and diagnostics message for activated condensed
status
A list of diagnostics events with status and diagnostics message for activated condensed status
is given in the following table. DIAGNOSTICS_EXTENSION and
DIAGNOSTICS_EXTENSION_2 are physical block parameters.
Functions/operations using PROFIBUS PA
9.3 Cyclic data transfer
SIPART PS2 with PROFIBUS PA
230 Operating Instructions, 05/2019, A5E00127926-AC
