Siemens SIPART PS2 User Manual

13.10.5 EMC filter module
Without Ex protection With Ex protection
Ex "ia", "ic"
With explosion protection
Ex "ec", "t"
The EMC filter module type 6DR4004-6F is required to connect electro-sensitive, external
position detection, e.g. NCS module type 6DR4004-6N*/-8N* or an external position detection system with
potentiometer type C73451-A430-D78 or 6DR4004-1ES.
For devices without explosion protection, other types of potentiometers with a resistance of 10 kilohms
can be connected.
Maximum values when powered by the
base unit with PA (6DR55) or FF commu‐
nication (6DR56)
U
max
= 5 V U
o
= 5 V
I
o
= 75 mA static
I
o
= 160 mA transient
P
o
= 120 mW
C
o
= 1 μF
L
o
= 1 mH
U
max
= 5 V
Peak values when supplied by other basic
devices (6DR50/1/2/3/9)
U
max
= 5 V U
o
= 5 V
I
o
= 100 mA
P
o
= 33 mW
C
o
= 1 μF
L
o
= 1 mH
U
max
= 5 V
Supply and signal power circuits Galvanically connected with the basic device
13.10.6 Internal NCS modules 6DR4004-5L and 6DR4004-5LE
Additional modules Without Ex protection With Ex protection
Ex "ia"
With explosion protection
Ex "ic", "ec", "t"
Internal NCS module 6DR4004-5L 6DR4004-5LE 6DR4004-5LE
Linearity (after corrections made by
positioner)
± 1 % ± 1 % ± 1 %
Hysteresis ± 0.2 % ± 0.2 % ± 0.2 %
13.10.7 Other technical specifications
Technical specifications for additional option modules and accessories is available at:
● Technical specifications NCS (Page 321)
● Technical specifications of the external position detection system (Page 326)
● Sealing plug / thread adapter (Page 331)
● Positioner with remote control electronics (Page 351)
