4.5.6 Internal NCS modules (iNCS) 6DR4004-5L and -5LE
Function
Wear-free, contact-free position detection
Device features






① Internal NCS module 6DR4004-5L. ④ Adjustment wheel for the magnet clamp
② Insulating cover, yellow ⑤ Adjustment wheel for the friction clutch (without
function)
③ Ribbon cable of the internal NCS mod‐
ule
Figure 4-19 Installing the internal NCS module, schematic diagram
Installing/mounting
