Wiring diagram
;
21
;
1
([WHUQDOSRVLWLRQ
GHWHFWLRQV\VWHPV
&$'
'5(6
'5(6
'5(6
'5(6
5HI
3RV
*1'
9FF
5HI
3RV
*1'
9FF
'5)Q([
6
6
21
6
6
6
6
5HI
3RV
*1'
9FF
'5)([
6
6
21
(0&ILOWHU
$QDORJ,QSXW0RGXOH
$,0
① Connection of terminal Vcc is only needed for 6DR4004-2ES, -3ES and -4ES.
B.3.3 Technical specifications of the external position detection system
Rated conditions
Ambient temperature In hazardous areas, observe the maximum permissible ambient
temperature corresponding to the temperature class.
● Permissible ambient temperature for operation
-40 ... +90 °C (-40 ... +194 °F)
Degree of protection
1)
IP66 / type 4X
Climate class According to IEC/EN 60721-3
● Storage
1K5, but -40 ... +90 °C (1K5, but -40 ... +194 °F)
● Transport
2K4, but -40 ... +90 °C (2K4, but -40 ... +194 °F)
● Operation
4K3, but -40 ... +90 °C (4K3, but -40 ... +194 °F)
1
) Impact energy max. 1 joule.
Construction
Material body
● C73451-A430-D78
Glass-fiber reinforced polycarbonate (PC)
● 6DR4004-1ES
Aluminum
Weight
● Enclosure C73451-A430-D78
Approx. 0.9 kg (1.98 lb)
● Enclosure 6DR4004-1ES
Approx. 1.6 kg (3.53 lb)
Torque for cable gland nut made of plastic See Construction (Page 282)
B.3.4 Scope of delivery of external position detection system
Scope of delivery of external position detection system C73451-A430-D78
Quan‐
tity
Designation
1 DVD with documentation
1 External position detection system
External position detection
B.3 External position detection system
SIPART PS2 with PROFIBUS PA
326 Operating Instructions, 05/2019, A5E00127926-AC
