E.8.2 For positioners in flameproof enclosure
<3=
<
0
GHHS[
0
GHHS[
%RRVWHU
E\SDVV
'$
'$
6$
6$
'$
6$
'$
SA Single-acting
DA Double-acting
Figure E-4 Dimension drawings booster mounted on positioner in a flameproof enclosure, dimensions
in mm (inch)
E.9 Technical specifications of booster
Booster
Vibration resistance
● Harmonic oscillations
According to ISA-S75.13
● Bumping (half-sine) according to EN 60068-2-27/02.2010
150 m/s² (492 ft/s²), 6 ms, 1000 shocks/axis
Climate class According to IEC/EN 60721-3
Booster
E.9 Technical specifications of booster
SIPART PS2 with PROFIBUS PA
Operating Instructions, 05/2019, A5E00127926-AC 349
