Description: A specific GSD file is allocated to every device operating mode. If the
configuration of your PROFIBUS PA path does not match the set
device operating mode, the device cannot accept the cyclic data
exchange. The station number and the device operating mode can‐
not be modified during ongoing communication with a master of
class 1.
A successfully established connection with a cyclic master can be
detected when the positioner responds to the setpoint of the master.
A blinking decimal point in the top line of the positioner display indi‐
cates communication with an acyclic master.
Factory setting: 1
See also
Cyclic data transfer (Page 209)
8.3.3 Extended diagnostics parameters A to P
8.3.3.1 Partial stroke test 'A.\\PST'
A.
PST - Partial Stroke Test
Condition: The parameter "52.XDIAG" is set to "On1", "On2" or "On3".
Possible settings: ● OFF
● On
Purpose: Use this parameter to activate and deactivate the partial stroke test.
To activate monitoring, assign the parameter value "On". Sub-pa‐
rameters are displayed.
Trigger the partial stroke test using:
● Buttons on the device
● A binary input
● Communication
● A cyclic test interval
The current status of the partial stroke test is displayed in the diag‐
nostic value "12.PST".
Diagnostic value "13.PRPST" and "14.NXPST" provide additional
information on the partial stroke test.
Factory setting: OFF
Parameter assignment
8.3 Description of parameters
SIPART PS2 with PROFIBUS PA
Operating Instructions, 05/2019, A5E00127926-AC 163
