Siemens SIPART PS2 - Maximal Permissible Ambient Temperature Ranges

Type of protection 6DR5ayb-*cdef-g*Ah-Zjjj Ex marking
ATEX/IECEx
Ex marking
FM-CSA
● For c = K and b = 1, 2, 3, 5, 6
● 6DR4004-1ES
External Position Transmitter
(Potentiometer)
● 6DR4004-2ES
External Position Transmitter (NCS)
II 2 G Ex ia IIC T6/T4 Gb
II 3 G Ex ic IIC T6/T4 Gc
II 2 D Ex ia IIIC T130°C Db
II 2 D Ex tb IIIC T100°C Db
II 3 G Ex ec IIC T6/T4 Gc
IS:
Cl I Zn 1 AEx ib IIC Gb
Cl I Zn 1 Ex ib IIC Gb
Zn 21 AEx ib IIIC, T130°C Db
Zn 21 Ex ib IIIC, T130°C Db
IS Cl I, II, III Div 1 Gp A-G
NI:
Cl I Zn 2 AEx nA IIC Gc
Cl I Zn 2 Ex nA IIC Gc
NI Cl I Div 2 Gp A-D
DIP:
Zn 21 AEx tb IIIC T100°C Db
Zn 21 Ex tb IIIC T100°C Db
DIP Cl II, III Div 1 Gp E-G
Intrinsic safety and increased safety (non-incen‐
dive NI)
● For c = F and b = 1, 2, 3, 5, 6
II 2 G Ex ia IIC T6/T4 Gb
II 3 G Ex ic IIC T6/T4 Gc
II 2 D Ex ia IIIC T130°C Db
II 3 G Ex ec IIC T6/T4 Gc
IS:
Cl I Zn 1 AEx ib IIC Gb
Cl I Zn 1 Ex ib IIC Gb
Zn 21 AEx ib IIIC T130°C Db
Zn 21 Ex ib IIIC T130°C Db
IS Cl I, II, III Div 1 Gp A-G
NI:
Cl I Zn 2 AEx nA IIC Gc
Cl I Zn 2 Ex nA IIC Gc
NI Cl I Div 2 Gp A-D
● 6DR4004-6N**-0-***
Non-Contacting Sensor (NCS)
13.5.3 Maximal permissible ambient temperature ranges
Positioner, modules and position detection sys‐
tems
Temperature class T4 Temperature class T6
Positioner
● 6DR5ayb-0cdef-g*Ah-Z jjj
-30 °C ≤Ta ≤ +80 °C -30 °C ≤Ta ≤ +50 °C
● 6DR5ayb-0cdef-g*Ah-Z M40
-40 °C ≤Ta ≤ +80 °C -40 °C ≤Ta ≤ +50 °C
● 6DR5ayb-0cdef-g*Ah-Z jjj
for a = 0, 2 and f = 0, 2
-30 °C ≤Ta ≤ +80 °C -30 °C ≤Ta ≤ +60 °C
● 6DR5ayb-0cdef-g*Ah-Z M40
for a = 0, 2 and f = 0, 2
-40 °C ≤Ta ≤ +80 °C -40 °C ≤Ta ≤ +60 °C
Position feedback module / Analog Output Mod‐
ule (AOM)
Technical data
13.5 Explosion protection
SIPART PS2 with PROFIBUS PA
Operating Instructions, 05/2019, A5E00127926-AC 285
