8.3.2.19 '47.\\STRK' Limit monitoring for the number of total strokes
Possible settings: 0 ... 1.00E9
Purpose: Use this parameter to set a limit for the number of total strokes. This
parameter corresponds to the profile parameter 'TO‐
TAL_VALVE_TRAVEL_LIMIT' and was applied for compatibility rea‐
sons.
Description: If the configured limit is exceeded, the 'CB_TOT_VALVE_TRAV' bit
is set in the profile parameter 'CHECK_BACK'.
This function enables preventive maintenance of the control valve.
Factory setting: 1E9
See also
Monitoring of number of total strokes 'L.\\STRK' (Page 182)
'50.XDIAG' Activation of extended diagnostics (Page 160)
Diagnostic value '1.STRKS - Number of total strokes' (Page 259)
8.3.2.20 '48.PRST' Preset
Possible settings: ● ALL
● Init
● PArA
● diAg
Purpose: Use this parameter to restore the factory settings for most parame‐
ters. The following parameter groups are available:
● ALL: Reset all parameters together which can be reset by 'Init',
'PArA' and 'diAg'.
● Init: Reset initialization parameters '1.YFCT' to '5.INITM'.
● PArA: Reset parameters '6.SDIR' to '47. STRK' and '51.FSTY'
Safety position (Page 161) to '53.FSVL' Safety setpoint
(Page 162).
● diAg: Reset parameters A to P of the extended diagnostics
function as well as parameter '50.XDIAG'.
An overview of the parameters and factory settings can be found in
section Tabular overview of the parameters (Page 134).
In order to select one of the parameter groups listed above, repeat‐
edly press the button until the desired setting is output in the
display. Start the function by keeping the button pressed until
'oCAY' is output in the display. The values of the parameter group
are now the factory settings.
Parameter assignment
8.3 Description of parameters
SIPART PS2 with PROFIBUS PA
158 Operating Instructions, 05/2019, A5E00127926-AC
