● BIN1 or BIN2 = PSt or -PSt
Using binary inputs 1 or 2, a partial-stroke test can be triggered
by actuation of your choice of a normally closed or normally
open switch.
● BIN1 or BIN2 = OFF
No function
Special function of binary input 1: If binary input 1 is activated in
"P-manual mode" by means of a jumper between terminals 9
and 10, the firmware version is displayed when the button is
pressed.
If one of the above functions is activated simultaneously with the
"BIN1" and "BIN2" parameters, then: "Blocking" has priority over
"uP". "uP" has priority over "doWn". "doWn" has priority over "PST".
Factory setting: OFF
8.3.2.14 '41.AFCT' Alarm function
Possible settings: See representation below
Purpose: This parameter can be used to determine the value at which going
above or below a given offset or angle will result in a message. The
triggering of alarms (limits) is relative to the MPOS scale. Alarms
are signaled through the alarm module. In addition, alarms can also
be read via the communication interface.
The direction of action of the binary outputs can be adjusted from
"High active" to "Low active" for the next system.
Factory setting: OFF
Parameter assignment
8.3 Description of parameters
SIPART PS2 with PROFIBUS PA
154 Operating Instructions, 05/2019, A5E00127926-AC
