Travel range WT00 WT05 WT10 WT30 WT50 WT70 WT90 WT95
Travel range section [%] - ≥ 5 ≥ 10 ≥ 30 ≥ 50 ≥ 70 ≥ 90 ≥ 95
< 5 < 10 < 30 < 50 < 70 < 90 < 95 -
Division of travel ranges
You can simultaneously set the eight operating hours counters to
zero.
TIP: Since the travel ranges are provided at the end of the diag‐
nostics parameters, press the button several times along with
the button. This will help you to access the desired diagnostics
parameters faster.
12.2.4.32 Diagnostics value '50.LKPUL - Length of the leakage compensation pulse'
Display range: -256 ... 0 ... 254
Purpose: This value in milliseconds indicates the length of a compensation
pulse when Monitoring/compensation of pneumatic leakage 'C.\
\LEAK' (Page 170) is active. The sign indicates the control direction
of the pulse.
Factory setting: 0
12.2.4.33 Diagnostics value '51.LKPER - Period of the leakage compensation pulse'
Display range: 0.00 ... 600.00
Purpose: This value in seconds indicates the period of the leakage compen‐
sation pulses when Monitoring/compensation of pneumatic leak‐
age 'C.\\LEAK' (Page 170) is active.
Factory setting: 0.00
12.3 Online diagnostics
12.3.1 Overview of online diagnostics
Online diagnostics means diagnostics during ongoing operation. A few important variables and
parameters are continuously monitored during the operation of the positioner. In
"Configuration" mode, you can configure this monitoring in such a way that the fault message
output will be activated if, for instance, a limit is exceeded.
Information about what events can activate the fault message output can be found in the table
in chapter "Overview of error codes (Page 272)".
Diagnostics and troubleshooting
12.3 Online diagnostics
SIPART PS2 with PROFIBUS PA
Operating Instructions, 05/2019, A5E00127926-AC 271
