Technical data
13
13.1 Rated conditions
Rated conditions
Ambient conditions For use indoors and outdoors.
Ambient temperature In hazardous areas, observe the maximum permissible am‐
bient temperature corresponding to the temperature class.
● Permissible ambient temperature for operation
2)3)
-30 ... +80 °C (-22 ... +176 °F)
● Height
2000 m above sea level. At altitudes greater than 2000 m
above sea level, use a suitable power supply.
● Relative humidity
0 ... 100%
Degree of pollution 2
Overvoltage category II
Degree of protection
1)
IP66 to IEC/EN 60529 / NEMA 4X
Mounting position Any; pneumatic connections and exhaust air outlet not fac‐
ing up in wet environment, Freezing of the exhaust air out‐
lets (Page 41)
Vibration resistance
● Harmonic oscillations (sine) according
to EN 60068-2-6/10.2008
3.5 mm (0.14"), 2 ... 27 Hz, 3 cycles/axle
98.1 m/s² (321.84 ft/s²), 27 ... 300 Hz, 3 cycles/axle
● Bumping (half-sine) according to EN 60068-2-27/02.2010
150 m/s² (492 ft/s²), 6 ms, 1000 shocks/axle
● Noise (digitally controlled) according to EN
60068-2-64/04.2009
10 ... 200 Hz; 1 (m/s²)²/Hz (3.28 (ft/s²)²/Hz)
200 ... 500 Hz; 0.3 (m/s²)²/Hz (0.98 (ft/s²)²/Hz)
4 hours/axle
● Recommended range of continuous operation of the entire
control valve
≤ 30 m/s² (98.4 ft/s²) without resonance peak
Climate class According to IEC/EN 60721-3
● Storage
1K5, but -40 ... +80°C (1K5, but -40 ... +176°F)
● Transport
2K4, but -40 ... +80°C (2K4, but -40 ... +176°F)
1)
Max. impact energy 1 Joule for enclosure with inspection window 6DR5..0 and 6DR5..1 or max. 2 Joule for 6DR5..3
2)
At ≤ -10 °C (≤ 14 °F) the display refresh rate of the indicator is limited. When using position feedback module, only T4 is
permissible.
3)
The following applies to order suffix (order code) -Z M40: -40 ... +80 °C (-40 ... +176°F)
SIPART PS2 with PROFIBUS PA
Operating Instructions, 05/2019, A5E00127926-AC 281
