6DR4004-.N.10 6DR4004-.N.40
1 2 Tensioning ring
4 4 Hexagon nut M6
2 2 Hex socket head screw M6x25
- 2 Hex socket head screw M3x12
1 1 Non-contacting sensor Cable lengths as ordered
1 1 Self-tapping screw for polycar‐
bonate enclosure
F3x8
1 1 Sealing For cable bushings
1 1 Plugs For closing the sealing insert
1 1 Cable clamp
1 1 DVD with documentation
B.2.7.2 Scope of delivery of NCS for linear actuators up to 14 mm (0.55 inch) .
Linear actuator with a stroke range up to 14 mm (0.55 inch) 6DR4004-.N.20
Quantity Designation Notes
1 Magnet
5 Washer 6
2 Hex socket head screw M6x12
4 Hexagon nut M6
2 Hex socket head screw M6x25
1 Non-contacting sensor Cable lengths as ordered
1 Screw F3x8
1 Sealing For cable bushings
1 Plugs For closing the sealing insert
1 Cable clamp
1 DVD with documentation
B.2.7.3 Scope of delivery of NCS for linear actuators > 14 mm (0.55 inch) .
Linear actuator > 14 mm (0.55 inch) 6DR4004-.N.30
Quantity Designation Notes
1 NCS assembly kit, completely
assembled
Mounting by means of assembly kit for NAMUR linear
actuators
Mounting kit available on separate order; refer to the 'Ac‐
cessories' section in Catalog FI 01
1 DVD with documentation
External position detection
B.2 Non-Contacting Sensor
SIPART PS2 with PROFIBUS PA
324 Operating Instructions, 05/2019, A5E00127926-AC
