4.5.1.3 Opening the device version with "flameproof enclosure"
Introduction
The following option modules are available for the positioner in the flameproof enclosure:
● Position feedback module 6DR4004-8J (Page 60)
● Alarm module 6DR4004-8A (Page 62)
● Internal NCS module 6DR4004-5LE (Page 70)
DANGER
Risk of explosion
Before supplying the positioner with auxiliary power in potentially hazardous areas, ensure the
following:
● The installed electronic unit has been approved.
● The enclosure of the positioner is closed.
● The duct openings for electronic connections must be closed. Only use the Ex d certified
cable entries or sealing plugs.
● If you use a "conduit piping system", install an ignition trap. The maximum distance
between the ignition trap and the positioner enclosure is 46 cm (18 inch).
Installing/mounting
4.5 Installing the optional modules
SIPART PS2 with PROFIBUS PA
56 Operating Instructions, 05/2019, A5E00127926-AC
