Siemens SIPROCESS GA700 User Manual

Functions
6.2 [2.01] Settings >Display/USER FUNC key
Operating with the Local User Interface
100 Operating Manual, 06/2017, A5E31930478-05
6.2.3
Displaying additional process values
Procedure
Note
Possible settings
With this parameter display you influence the additional process value display in the main
view. The offered settings depend on the following conditions:
•
Hardware installed in device
•
Parameter assignment of the analog input
•
Active MODBUS communication
1. Main menu > "2 Settings" > "01. Display/USER FUNC key" > "3. Additional process
values"
2. Call the parameter display: Press <Enter>.
The parameter display includes one editable parameter field for the six display lines that
can be set.
3. Open "Line n" parameter field. Authorize access with Standard PIN, if necessary.
4. Select offered process values. The following external process values can be selected:
– No display
– All measured pressures
– All sample gas flows
– All reference gas flows (O7)
– Humidity
– All MODBUS TCP components: → MODBUS TCP node (Page 223).
– All analog inputs (number of the analog input and name): → [1] Analog inputs
(Page 221).
You can find information about the concentration values of external correction of cross-
interference sources under → Setting the correction of cross-interference (Page 168).
5. Repeat steps 3 and 4 for required additional displays.
