6.4 [2.03] Settings > Measuring ranges
Operating with the Local User Interface
Operating Manual, 06/2017, A5E31930478-05
105
So
H
High switchover point (= start value of
measuring range)
So
L
Low switchover point (= start value plus
10% of the span)
FSV
Full-scale value
SSV
Start-of-scale value
When the high switchover point is violated, there will be a switch to the next-higher
measuring range. If the measured value violates the low switchover point of the next-lower
measuring range, the device switches to the lower measuring range.
6.4.2
Setting the measuring ranges
Procedure
Note
Component-specific setting
Measuring ranges are component
-specific. Repeat the procedure described below for all
components, if necessary.
1. Component > Main menu > "2 Settings" > "03 Measuring ranges"
The menu includes a navigation line for setting of autoranging.
One navigation line is reserved for each of the four measuring ranges that can be set:
Structure of the navigation line for each measuring range
Measuring range
1 to 4
Measuring range start - measuring range end Activation status
1)
Edit
1)
On/Off: signals if the measuring range is currently active and in use.
2. Open selected measuring range: Press <ENTER>.
The parameter display of the measuring range is opened.
