A.5 MODBUS TCP
Operating with the Local User Interface
288 Operating Manual, 06/2017, A5E31930478-05
A.5.3
Transfer of device data
A.5.3.1
Device data
Transfer from the analyzer to the process control system
Table A- 12 Device identification data
Object ID
Object name / description
Category
Type
Object
length
Coding
0x00
VendorName
Basic
STRING
0x0C
0x01 ProductCode Basic STRING 0x30
0x02
MajorMinorRevision
Basic
STRING
0x10
0x04 ProductName Regular STRING 0x10
0x06
UserApplicationName
Regular
STRING
0x20
0x80
SerialNumber
Extended
STRING
0x10
0x81 Component1_Code Extended UINT8 0x01 Table A-14 MODBUS TCP: Cod-
ing of gas components [Object ID
0x81, 0x87, 0x8D, 0x93, 0x99,
0x0000, 0x000C, 0x0018,
0x0024, 0x0030] (Page 298)
0x82
Component1_Name
Extended
STRING
0x20
0x83 Component1_UnitCode Extended UINT16 0x02 Table A-15 MODBUS TCP: Cod-
ing of component units [Object ID
0x83, 0x89, 0x8F, 0x95, 0x9B,
0x0001, 0x000D, 0x0019,
0x0025, 0x0031] (Page 299)
0x84
Component1_UnitName
Extended
STRING
0x08
0x85
Component1_RangeBegin
Extended
FLOAT32
0x04
0x86
Component1_RangeEnd
Extended
FLOAT32
0x04
0x87 Component2_Code Extended UINT8 0x01 Table A-14 MODBUS TCP: Cod-
ing of gas components [Object ID
0x81, 0x87, 0x8D, 0x93, 0x99,
0x0000, 0x000C, 0x0018,
0x0024, 0x0030] (Page 298)
0x88
Component2_Name
Extended
STRING
0x20
0x89 Component2_UnitCode Extended UINT16 0x02 Table A-15 MODBUS TCP: Cod-
ing of component units [Object ID
0x83, 0x89, 0x8F, 0x95, 0x9B,
0x0001, 0x000D, 0x0019,
0x0025, 0x0031] (Page 299)
0x8A
Component2_UnitName
Extended
STRING
0x08
0x8B
Component2_RangeBegin
Extended
FLOAT32
0x04
0x8C
Component2_RangeEnd
Extended
FLOAT32
0x04
