Functions
6.24 [3.11] Maintenance & Diagnostics > Test
Operating with the Local User Interface
238 Operating Manual, 06/2017, A5E31930478-05
5. Enter setpoints for additional analog outputs, if necessary: Repeat steps 2 to 4.
6. Enable/disable test mode:
Main menu > "3. Maintenance & diagnostics" > "11. Test" > "1. Test inputs/outputs" >
"1. Analog outputs" > "1. Test mode" > "Test mode" parameter box:
– When you enable test mode, the analog outputs can only be used for test purposes.
This operational status can only be recognized by the function control indicators in the
status bar
(Symbol "Hand, 2 points") or (Symbol "Screw wrench" → Table 7-1
Function check indicators (Page 255).
– Disable the function directly after the test is complete.
7. Measure/check test signal externally.
8. Disable test mode:
Main menu > "3. Maintenance & diagnostics" > "11. Test" > "1. Test inputs/outputs" >
"1. Analog outputs" > "1. Test mode" > "Test mode" parameter box
When you disable test mode, the analog outputs work once again according to their
parameter assignment.
LUI symbol sets (Page 255)
Testing analog inputs
Requirement
Note
Availability of the menu
This menu is only availab
le if your device has at least one of the option modules (2.1 and/ or
● Make sure that a suitable test device is connected.
● When entering the setpoint using internal analog outputs: The analog outputs of the used
option module must be connected to the analog inputs of the option module 2.
● When entering the setpoint using external analog outputs: Current signal must be applied
externally. Make sure that the analog inputs are wired accordingly.
