Functions
6.8 [2.09] Settings > Inputs/outputs
Operating with the Local User Interface
Operating Manual, 06/2017, A5E31930478-05
155
See also
Setting functions/components of a digital output (Page 156)
6.8.5.3
Setting digital outputs
Procedure
1. Main menu > "2. Settings" > "09. Inputs/outputs" > "5 Digital outputs"
The menu includes navigation lines for access to all available digital outputs. The number
of available digital outputs depends on the hardware of your device.
Structure of the navigation line for each digital output
Navigation
no.
1) 2) 3)
DO name Function Component
4)
Edit
1)
Standard: Digital outputs 01 to 08.
2)
Only with optional module 1: Digital outputs 09 to 20.
3)
Cannot be configured: Digital outputs 21 to 23 (analyzer module 1), digital outputs 24 to 26
(analyzer module 2).
4)
Display only for function (pre-selection) "Limit", "Solenoid valve", "Measuring range"
2. Open selected digital output: press <ENTER>.
The parameter display of a digital output whose parameters have not yet been assigned
contains the "Function (pre-selection)" and "Function" parameters boxes, each with the
setting "Free".
3. Define function group: "Function (pre-selection)" parameter box.
The selection of the function group determines additional setting or display options.
