Siemens SIPROCESS GA700 User Manual

Functions
6.7 [2.08] Settings > Calibrations
Operating with the Local User Interface
134 Operating Manual, 06/2017, A5E31930478-05
4. Make any additional settings, if necessary:
Process
Parameter fields to be set
Calibration 01 to 36 Enter purge time per calibration point.
Purge time, here: Time for which the device remains at the cali-
bration point. The purge time must be at least as long as the
noise suppression time. Set the purge time so that the measur-
ing chamber is completely filled with calibration gas before the
start of calculations.
Sample gas purging Purge time, here: Time during which the sample gas is intro-
duced.
Measuring mode Purge time, here: Time the device stays in "Measurement" oper-
ating state.
Only passive CAL
No additional settings in this menu. Sequence step is skipped.
Signaling contact No additional settings in this menu.
Time during which a digital output that is assigned as a signaling
contact is set for more than one second.
Signaling contact: AutoCal signaling contact, 1000 ms pulse.
Assigned to digital output
1)
.
AutoCal 2
No additional settings in this menu.
1)
The signaling contact allows you to trigger an AutoCal/AutoVal sequence on a second device,
and signal the start/end of a sequence.
5. Configure the operating mode of AutoCal/AutoVal: → Setting the AutoCal/AutoVal mode
(Page 134).
See also
Overview of digital inputs (Page 143)
6.7.6.3
Setting the AutoCal/AutoVal mode
Requirement
The following requirements must be met before you specify the operating mode or start an
AutoCal/AutoVal:
● Calibration pool entries are available.
● The calibration/validation sequence has been configured:→ Setting the AutoCal/AutoVal
sequence (Page 132).
