Siemens SIPROCESS GA700 User Manual

Functions
6.19 [3.05] Maintenance & Diagnostics > Diagnostics values
Operating with the Local User Interface
Operating Manual, 06/2017, A5E31930478-05
219
Only ULTRAMAT 7: predictive self-diagnostics
Table 6- 58 ULTRAMAT 7: [3.05.2] Predictive self-diagnostics
Parameter
Description
Source intensity High alarm limit Maximum positive deviation of the source intensity (in %). A
maintenance alarm is signaled on a high limit violation.
High warning limit Maximum positive deviation of the source intensity (in %). A
maintenance demanded is signaled on a high limit violation.
Current deviation Percentage deviation of the current intensity I
0
from the
normalized intensity I
0 norm
.
Low warning limit Maximum negative deviation of the source intensity (in %). A
maintenance demanded is signaled on a low limit violation.
Low alarm limit Maximum negative deviation of the source intensity (in %). A
maintenance alarm is signaled on a low limit violation.
Intensity I
0
TC
Source intensity I
0
after temperature compensation
6.19.3
[3.05.3] Electric parameters
Overview
In this menu you access information/current values that you can use to evaluate the supply
status of the device. The menu shows the modules installed in the device for which electrical
parameters are available. This includes analyzer modules and any installed option modules.
The menu can include up to three navigation lines, depending on the features:
You only have read access.
Navigation lines in the menu [3.05.03]
Navigation number
1)
Module name
2)
Component/ module
type
3)
Display details ►
1)
AM1 → "1.", AM2 → "2.", OM2 → "4."; "3" currently not assigned.
2)
Depending on features: AM1, AM2, OM2
3)
Gas component or module type, for OM2, e.g., "AI/DI"
