Functions
6.8 [2.09] Settings > Inputs/outputs
Operating with the Local User Interface
148 Operating Manual, 06/2017, A5E31930478-05
6.8.3.2
Setting digital inputs
Procedure
1. Main menu > "2 Settings" > "09 Inputs/outputs" > "3 Digital inputs"
Up to 20 digital inputs can be assigned, depending on the hardware of your device. A
navigation line with the following structure is assigned to each digital input:
Structure of the navigation line for each digital input
Navigation no.
1)
DI name Function Component
2)
Additional text
3)
Edit
1)
Standard: Digital inputs 01 ... 08
With option module 1.1 additionally: Digital inputs 09 ... 16.
With option module 2.2 additionally: Digital inputs 17 to 20.
2)
Display for function "Measuring range n" only
3)
Display for externally controlled functions only
2. Open selected digital input: Press <ENTER>.
The factory-set parameter display of a digital input whose parameters have not yet been
assigned has two parameter boxes:
– "DI active for" parameter box, setting "High"
– "Function (pre-selection)" parameter box, setting "Free"
3. Set the trigger: "DI active for" parameter box.
Use the information in → Overview of digital inputs (Page 143) when setting the activation
level.
