Functions
6.4 [2.03] Settings > Measuring ranges
Operating with the Local User Interface
106 Operating Manual, 06/2017, A5E31930478-05
3. Set up the measuring range:
Refer to the specifications under Overview of measuring ranges (Page 103).
– Enter start of measuring range: "Start-of-scale value" parameter box
Authorize access with Standard PIN, if necessary.
– Enter end of measuring range: "Full-scale value" parameter box.
Note
Adjustment aids: Distance between the start-of-scale value and full-scale value
When you set the measuring ranges, the maximum and
minimum selectable values are
displayed in the relevant editing window. Changing the start
-of-scale or full-scale value of
a measuring range can nevertheless lead to a violation of the smallest measuring range
span. The changes are then rejected.
If necessary, change the order in which you make the settings (full-scale value before
start-of-scale value)
Make sure that the smallest measuring range span is not violated. The smallest
selectable measuring range span is 20% of the smallest measuring range. Use the
following example as a basis:
Smallest measuring span = 5000 ppm ⇒ between the measuring range start value and
measuring range end value there must be at least 1000 ppm (5000 ppm x 20 % =
4. Enable/disable measuring range: "Use measuring range" parameter box.
Note
Using measuring ranges in other device functions / menus
Other device functions or menus can only access measuring ranges activated in this
menu. Inactive measuring ranges are no longer displayed in other device functions /
men
us. Using them, for example for autoranging or in calibrations is then no longer
5. Set additional measuring ranges/parameters, e.g., Setting Autoranging (Page 106).
Setting Autoranging
Procedure
Note
Autoranging
Autoranging is not possible if the measuring ranges were set incorrectly. In this case
measuring range 1 is selected as active measuring range.
