Siemens SIPROCESS GA700 User Manual

Functions
6.2 [2.01] Settings >Display/USER FUNC key
Operating with the Local User Interface
Operating Manual, 06/2017, A5E31930478-05
101
6.2.4
Customizing the display settings
Procedure
1. Main menu > "2 Settings" > "01. Display/USER FUNC key" > "4. Display settings"
2. Call the parameter display: Press <Enter>.
3. Make the display settings:
– Set contrast brighter or darker: "Contrast" parameter field.
– Set the backlighting brighter or darker: "Backlighting" parameter field.
Increase/lower values by pressing the displayed arrow keys.
6.2.5
Setting the symbol sets
Procedure
Note
Symbol sets
The device offers two symbol sets that the device uses to signal status messages. You can
find information on symbol sets for NAMUR or SIMATIC
PCS 7 under → LUI symbol sets
(Page
255).
1. Main menu > "2 Settings" > "01 Display/USER FUNC key" > "5 Symbols"
2. Call the parameter display: Press <Enter>.
3. Select the symbol set: "Show symbols" parameter field.
– Authorize access with Standard PIN, if necessary.
– Set symbol set "NAMUR" or "PCS7".
The PCS7 symbol set is more comprehensive and gives you a more detailed image of
the device status.
