Yealink VC110 Administrator's Guide

Administrator’s Guide for Yealink VC110 Video Conferencing Endpoint
86
3. Click Confirm to accept the change.
To configure H.323 tunneling via the remote control:
1. Select Menu->Advanced (default password: 0000) ->H.323.
2. Check the H.323 Tunneling checkbox.
3. Press the Save soft key to accept the change.
Configuring the Endpoint for Use with a Firewall or
NAT
A firewall protects an organization’s IP network by controlling data traffic from outside the
network. Unless the firewall is designed to work with video conferencing equipment, you must
configure the firewall to allow incoming and outgoing traffic to the VC110 endpoint through the
reserved ports. Users placing calls through a firewall to endpoints may experience one-way
audio or video if the firewall is not properly configured.
Call Setup and Media Ports
To place calls to other endpoints through the firewall, you must configure your firewall to allow
incoming and outgoing traffic to the system through the following:
Description
Port Range
Port Type
Gatekeeper
1719
UDP
H.323 signal port
1720
TCP
SIP (default transport protocol)
5060
UDP
SIP (when selecting the TCP transport
protocol)
5060
TCP
SIP (when selecting the TLS transport
protocol)
5061
TCP
Reserved ports of the endpoint.
50000-50499
TCP/UDP

Yealink VC110 Specifications

General

Digital zoom	4 x
Focus adjustment	Auto
Video codecs	H.264, H.263
Maximum frame rate	30 fps
Supported video modes	720p, 1080p
Video formats supported	H.263, H.264
Supported graphics resolutions	352 x 288, 704 x 576, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Voice codecs	G.711a, G.722, G.722.1, G.722.1C
Line-in	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Pan range	-100 - 100 °
Tilt angle range	-30 - 30 °
Security algorithms	128-bit AES, HTTPS, SRTP, SSL/TLS
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols	TCP/IP (IPv4), DHCP/ stastic IP, HTTP/ HTTPS, SRTP/TLS, IEEE802.1X, LLDP-MED, VLAN
Current	2 A
Power consumption (max)	30 W
Power consumption (typical)	24 W
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	151.5 mm
Width	234.6 mm
Height	161 mm
Package depth	318 mm
Package width	432 mm
Package height	274 mm
Package weight	5900 g
