Yealink VC110 Administrator's Guide

Configuring Call Preferences
165
4. Click Confirm to accept the change.
Ringback Timeout
Ringback timeout defines a specific period of time within which the VC110 video conferencing
endpoint will cancel the dialing if the call is not answered.
The ringback timeout parameter on the endpoint is described below:
Parameter
Description
Configuration Method
Ringback Timeout
(30-240)
Configures the duration time (in
seconds) in the ringback state.
Default: 200
If it is set to 200, the endpoint will
cancel the dialing if the call is not
answered within 200s.
Web User Interface
To configure ringback timeout via web user interface:
1. Click on Setting->Call Features.
2. Select the desired value from the pull-down list of Ringback Timeout(30-240).
3. Click Confirm to accept the change.

Yealink VC110 Specifications

General

Digital zoom	4 x
Focus adjustment	Auto
Video codecs	H.264, H.263
Maximum frame rate	30 fps
Supported video modes	720p, 1080p
Video formats supported	H.263, H.264
Supported graphics resolutions	352 x 288, 704 x 576, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Voice codecs	G.711a, G.722, G.722.1, G.722.1C
Line-in	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Pan range	-100 - 100 °
Tilt angle range	-30 - 30 °
Security algorithms	128-bit AES, HTTPS, SRTP, SSL/TLS
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols	TCP/IP (IPv4), DHCP/ stastic IP, HTTP/ HTTPS, SRTP/TLS, IEEE802.1X, LLDP-MED, VLAN
Current	2 A
Power consumption (max)	30 W
Power consumption (typical)	24 W
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	151.5 mm
Width	234.6 mm
Height	161 mm
Package depth	318 mm
Package width	432 mm
Package height	274 mm
Package weight	5900 g
