Yealink VC110 Administrator's Guide

VC110 Video Conferencing Endpoint Introduction
31
VCR10 Remote Control
VCR10 remote control is compact, and has definite function zoning. Users can organize
conferences easily using infrared signals.
Hardware components of the remote control:
Item
Description
①
Sleep Key
Puts the endpoint to sleep or wakes the endpoint up.
②
Red Shortcut Key
Located at the bottom left of the screen. Label automatically
identifies context-sensitive features.
In the idle screen, this is used to enter the main menu screen
and corresponds to the Menu soft key.
③
Yellow Shortcut Key
Located at the bottom center of the screen. Label
automatically identifies context-sensitive features.
In the idle screen, this is used to enter the pre-dialing screen,
and corresponds to the Call soft key.

Yealink VC110 Specifications

General

Digital zoom	4 x
Focus adjustment	Auto
Video codecs	H.264, H.263
Maximum frame rate	30 fps
Supported video modes	720p, 1080p
Video formats supported	H.263, H.264
Supported graphics resolutions	352 x 288, 704 x 576, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Voice codecs	G.711a, G.722, G.722.1, G.722.1C
Line-in	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Pan range	-100 - 100 °
Tilt angle range	-30 - 30 °
Security algorithms	128-bit AES, HTTPS, SRTP, SSL/TLS
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols	TCP/IP (IPv4), DHCP/ stastic IP, HTTP/ HTTPS, SRTP/TLS, IEEE802.1X, LLDP-MED, VLAN
Current	2 A
Power consumption (max)	30 W
Power consumption (typical)	24 W
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	151.5 mm
Width	234.6 mm
Height	161 mm
Package depth	318 mm
Package width	432 mm
Package height	274 mm
Package weight	5900 g
