Yealink VC110 Administrator's Guide

Administrator’s Guide for Yealink VC110 Video Conferencing Endpoint
116
4. Configure the StarLeaf Cloud platform.
5. Click Confirm to accept the change.
To configure StarLeaf Cloud platform via the remote control:
1. Select Menu->Advanced (default password: 0000)->Video Conference Platform.
2. In the Cloud Account field, check the Enabled checkbox.
3. Select StarLeaf from the pull-down list of Platform Type.
4. Enter the 12-digit quick access code in the QCP Code field.
5. Press or to scroll to Log In, and then press .
After successful registration, the display device displays , and the LCD screen of the
video conferencing phone displays .
Note
Logging into the Zoom Cloud Platform
You can log into the Zoom Cloud platform and join the VMR.
Zoom Cloud platform parameters on the endpoint are described below:
Parameter
Description
Configuration Method
Cloud Account
Enables or disables the Cloud feature.
Remote Control
Endpoints that log into the StarLeaf Cloud platform will upgrade firmware automatically once the
current firmware version is different from the one on StarLeaf Server.

Yealink VC110 Specifications

General

Digital zoom	4 x
Focus adjustment	Auto
Video codecs	H.264, H.263
Maximum frame rate	30 fps
Supported video modes	720p, 1080p
Video formats supported	H.263, H.264
Supported graphics resolutions	352 x 288, 704 x 576, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Voice codecs	G.711a, G.722, G.722.1, G.722.1C
Line-in	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Pan range	-100 - 100 °
Tilt angle range	-30 - 30 °
Security algorithms	128-bit AES, HTTPS, SRTP, SSL/TLS
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols	TCP/IP (IPv4), DHCP/ stastic IP, HTTP/ HTTPS, SRTP/TLS, IEEE802.1X, LLDP-MED, VLAN
Current	2 A
Power consumption (max)	30 W
Power consumption (typical)	24 W
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	151.5 mm
Width	234.6 mm
Height	161 mm
Package depth	318 mm
Package width	432 mm
Package height	274 mm
Package weight	5900 g
