Yealink VC110 Administrator's Guide

Administrator’s Guide for Yealink VC110 Video Conferencing Endpoint
250
Parameter
Description
Configuration Method
Note: It can only be configured
when the user mode is enabled. The
endpoint supports ASCII characters
32-126(0x20-0x7E) in passwords.
You can leave the password blank.
To configure user mode via web user interface:
1. Click on Security->Security.
2. Select User from the pull-down list of User Type.
3. Select Enabled from the pull-down list of User Mode.
4. Configure a password or leave it blank in the User Password field.
5. Click Confirm to accept the change.
Administrator Password
The default enabled user type is administrator. Users can log into the web user interface and
access the “Advanced” menu with administrator privilege by default. The default administrator
password is “0000” and can be only changed by an administrator. For security reasons, the
administrator should change the default administrator password as soon as possible. The
endpoint supports ASCII characters 32-126(0x20-0x7E) in passwords.
Administrator password parameters on the endpoint are described below:
Parameter
Description
Configuration Method
User Type
Specifies the user type.
Default: Administrator
Note: To configure a new
administrator password, you need to
select Administrator for this
parameter.
Web User Interface
Old Password
Enters the old administrator
password.
Note: The default administrator
password is “0000”.
Remote Control
Web User Interface

Yealink VC110 Specifications

General

Digital zoom	4 x
Focus adjustment	Auto
Video codecs	H.264, H.263
Maximum frame rate	30 fps
Supported video modes	720p, 1080p
Video formats supported	H.263, H.264
Supported graphics resolutions	352 x 288, 704 x 576, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Voice codecs	G.711a, G.722, G.722.1, G.722.1C
Line-in	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Pan range	-100 - 100 °
Tilt angle range	-30 - 30 °
Security algorithms	128-bit AES, HTTPS, SRTP, SSL/TLS
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols	TCP/IP (IPv4), DHCP/ stastic IP, HTTP/ HTTPS, SRTP/TLS, IEEE802.1X, LLDP-MED, VLAN
Current	2 A
Power consumption (max)	30 W
Power consumption (typical)	24 W
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	151.5 mm
Width	234.6 mm
Height	161 mm
Package depth	318 mm
Package width	432 mm
Package height	274 mm
Package weight	5900 g
