Yealink VC110 Administrator's Guide

Administrator’s Guide for Yealink VC110 Video Conferencing Endpoint
152
5. (Optional.) If Yealink device has audio problems with certain device, select Enabled from
the pull-down list of Special audio codec byte sequence.
6. Click Confirm to accept the change.
Video Codecs
The video codec that the endpoint uses to establish a call should be supported by the server.
When placing a call, the endpoint will offer the enabled video codec list to the server and then
use the video codec negotiated with the called party according to the priority.
The following table summarizes the supported video codecs on the endpoint:
Name
MIME Type
Bit Rate
Frame Rate
Frame Size
H.264 High
Profile
H264/90000
90 kbps to
2048 kbps
5 fps to
30 fps
Tx: WQVGA,360P, 448P,
540P, 720P, 1080P
Rx: Conventional Size
Below 1080P
H.264
H264/90000
H.263
H263/90000
Tx: CIF, 4CIF
RX: QCIF, CIF, 4CIF

Yealink VC110 Specifications

General

Digital zoom	4 x
Focus adjustment	Auto
Video codecs	H.264, H.263
Maximum frame rate	30 fps
Supported video modes	720p, 1080p
Video formats supported	H.263, H.264
Supported graphics resolutions	352 x 288, 704 x 576, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Voice codecs	G.711a, G.722, G.722.1, G.722.1C
Line-in	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Pan range	-100 - 100 °
Tilt angle range	-30 - 30 °
Security algorithms	128-bit AES, HTTPS, SRTP, SSL/TLS
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols	TCP/IP (IPv4), DHCP/ stastic IP, HTTP/ HTTPS, SRTP/TLS, IEEE802.1X, LLDP-MED, VLAN
Current	2 A
Power consumption (max)	30 W
Power consumption (typical)	24 W
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	151.5 mm
Width	234.6 mm
Height	161 mm
Package depth	318 mm
Package width	432 mm
Package height	274 mm
Package weight	5900 g
