Yealink VC110 Administrator's Guide

Endpoint Maintenance
273
2. Click Browse to locate a configuration file from your local endpoint.
3. Click Import to import the configuration file.
Resetting to Factory
Reset the endpoint to factory configurations after you have tried all appropriate
troubleshooting suggestions but still have not solved your problems.
When factory resetting the video endpoint, the following happens:
 The call logs will be deleted.
 Passwords will be reset to default.
 All system parameters will be reset to default values.
 All custom files will be deleted. Such as, certificates, local contacts and registered accounts.
It is not possible to undo a factory reset. But you can export the configuration first, and then you
can re-import the configuration to recovery the endpoint after the reset.
You can reset the endpoint via the reset key on the VC110 all-in-one unit, remote control or web
user interface.
Note
To reset the endpoint via web user interface:
1. Click on Setting->Upgrade.
Reset of the endpoint may take a few minutes. Do not power off until the phone starts up
successfully.

Yealink VC110 Specifications

General

Digital zoom	4 x
Focus adjustment	Auto
Video codecs	H.264, H.263
Maximum frame rate	30 fps
Supported video modes	720p, 1080p
Video formats supported	H.263, H.264
Supported graphics resolutions	352 x 288, 704 x 576, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Voice codecs	G.711a, G.722, G.722.1, G.722.1C
Line-in	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Pan range	-100 - 100 °
Tilt angle range	-30 - 30 °
Security algorithms	128-bit AES, HTTPS, SRTP, SSL/TLS
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols	TCP/IP (IPv4), DHCP/ stastic IP, HTTP/ HTTPS, SRTP/TLS, IEEE802.1X, LLDP-MED, VLAN
Current	2 A
Power consumption (max)	30 W
Power consumption (typical)	24 W
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	151.5 mm
Width	234.6 mm
Height	161 mm
Package depth	318 mm
Package width	432 mm
Package height	274 mm
Package weight	5900 g
