Yealink VC110 Administrator's Guide

Getting Started
41
Getting Started
This chapter provides basic information and installation instructions for Yealink VC110
endpoints in the following sections:
 Endpoint Connection and Installation
 Powering the Endpoint On or Off
 Endpoint Initialization
 Endpoint Startup
 Setup Wizard
 Enabling Communication with Other Endpoints
 Placing a Test Call from the Yealink VC110 endpoint
Endpoint Connection and Installation
Placing the Endpoint
Do not place the camera facing a window or other bright light. Ensure sufficient space to
connect the cables. Ensure all participants are facing both the display device and the camera at
the same time by putting camera and display device together.
Endpoint Components Installation
This section introduces the following:
 Connecting the VC110 video conferencing endpoint
 Installing the VC110 video conferencing endpoint
 Installing batteries in the remote control
Note
Up to two display devices can be connected to the VC110 all-in-one unit. Because the display
device is not included in the package, you need to purchase it separately if required. Ensure that
the purchased display device supports HDMI input.
When connecting only one display device to the VC110 all-in-one unit, Display1 port is the only
available port. If dual screen mode is required, you can connect secondary display device to the
Display2 port.
Because DVI cable is tailor-made, please use the Yealink-supplied DVI cable.
To prevent shock, do not connect the power adapter and turn on the power before connecting
all endpoint components.

Yealink VC110 Specifications

General

Digital zoom	4 x
Focus adjustment	Auto
Video codecs	H.264, H.263
Maximum frame rate	30 fps
Supported video modes	720p, 1080p
Video formats supported	H.263, H.264
Supported graphics resolutions	352 x 288, 704 x 576, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Voice codecs	G.711a, G.722, G.722.1, G.722.1C
Line-in	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Pan range	-100 - 100 °
Tilt angle range	-30 - 30 °
Security algorithms	128-bit AES, HTTPS, SRTP, SSL/TLS
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols	TCP/IP (IPv4), DHCP/ stastic IP, HTTP/ HTTPS, SRTP/TLS, IEEE802.1X, LLDP-MED, VLAN
Current	2 A
Power consumption (max)	30 W
Power consumption (typical)	24 W
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	151.5 mm
Width	234.6 mm
Height	161 mm
Package depth	318 mm
Package width	432 mm
Package height	274 mm
Package weight	5900 g
