Yealink VC110 Administrator's Guide

Configuring Endpoint Settings
215
Parameter
Description
Configuration Method
to Enabled.
To configure far-end camera control via web user interface:
1. Click on Setting->Video & Audio.
2. Enter the desired time in the Not FECC in call(0~300s) field.
3. Select the desired values from the pull-down lists of Far Control Near Camera.
4. Select the desired values from the pull-down lists of Far Set of Camera Presets.
5. Select the desired values from the pull-down lists of Far Move to Camera Presets.
6. Click Confirm to accept the change.
To configure far-end camera control feature via the remote control:
1. Select Menu->Video & Audio->Far-end Camera Control.
2. Make the desired changes.
3. Press the Save soft key to accept the change.
Camera Control Protocol
VC110 video conferencing endpoint supports camera control protocols: FECC (Far End Camera
Control). You can enable the FECC protocol for SIP call or H.323 call.
If far site wants to control the local camera, both the far site and local site should enable the
camera control protocol simultaneously. If the FECC protocol is not enabled on either site,
far-end camera control cannot be performed. For example, a SIP call is established between two

Yealink VC110 Specifications

General

Digital zoom	4 x
Focus adjustment	Auto
Video codecs	H.264, H.263
Maximum frame rate	30 fps
Supported video modes	720p, 1080p
Video formats supported	H.263, H.264
Supported graphics resolutions	352 x 288, 704 x 576, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Voice codecs	G.711a, G.722, G.722.1, G.722.1C
Line-in	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Pan range	-100 - 100 °
Tilt angle range	-30 - 30 °
Security algorithms	128-bit AES, HTTPS, SRTP, SSL/TLS
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols	TCP/IP (IPv4), DHCP/ stastic IP, HTTP/ HTTPS, SRTP/TLS, IEEE802.1X, LLDP-MED, VLAN
Current	2 A
Power consumption (max)	30 W
Power consumption (typical)	24 W
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	151.5 mm
Width	234.6 mm
Height	161 mm
Package depth	318 mm
Package width	432 mm
Package height	274 mm
Package weight	5900 g
