Yealink VC110 Administrator's Guide

Configuring Endpoint Settings
183
2. Select desired value from the pull-down list of Automatic Sleep Time.
3. Click Confirm to accept the change.
To configure the automatic sleep time via the remote control:
1. Select Menu->Basic.
2. Select desired value from the pull-down list of Automatic Sleep Time.
3. Press the Save soft key to accept the change.
Hiding IP Address
The status bar of the display device displays IP address. You can choose to hide IP address on
the status bar.
The hide IP address parameter is described below:
Parameter
Description
Configuration Method
Hide IP address
Enables or disables the endpoint to
hide IP address.
Default: Disabled
Web User Interface

Yealink VC110 Specifications

General

Digital zoom	4 x
Focus adjustment	Auto
Video codecs	H.264, H.263
Maximum frame rate	30 fps
Supported video modes	720p, 1080p
Video formats supported	H.263, H.264
Supported graphics resolutions	352 x 288, 704 x 576, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Voice codecs	G.711a, G.722, G.722.1, G.722.1C
Line-in	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Pan range	-100 - 100 °
Tilt angle range	-30 - 30 °
Security algorithms	128-bit AES, HTTPS, SRTP, SSL/TLS
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols	TCP/IP (IPv4), DHCP/ stastic IP, HTTP/ HTTPS, SRTP/TLS, IEEE802.1X, LLDP-MED, VLAN
Current	2 A
Power consumption (max)	30 W
Power consumption (typical)	24 W
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	151.5 mm
Width	234.6 mm
Height	161 mm
Package depth	318 mm
Package width	432 mm
Package height	274 mm
Package weight	5900 g
