Yealink VC110 Administrator's Guide

Administrator’s Guide for Yealink VC110 Video Conferencing Endpoint
222
3. Select the desired value from the pull-down list of Display2.
4. Click Confirm to accept the change.
USB Configuration
If you have high requirement for data security, you can disable the USB feature. If you disable
the USB feature, you cannot view the videos and screenshots stored in the USB flash driver via
the remote control, and cannot record video or capture screenshots too.
The USB configuration parameter on the endpoint is described below.
Parameter
Description
Configuration Method
USB Enable
Enables or disables the USB feature.
Default: Enabled
Web User Interface
To configure USB configuration via web user interface:
1. Click on Setting->Video & Audio.

Yealink VC110 Specifications

General

Digital zoom	4 x
Focus adjustment	Auto
Video codecs	H.264, H.263
Maximum frame rate	30 fps
Supported video modes	720p, 1080p
Video formats supported	H.263, H.264
Supported graphics resolutions	352 x 288, 704 x 576, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Voice codecs	G.711a, G.722, G.722.1, G.722.1C
Line-in	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Pan range	-100 - 100 °
Tilt angle range	-30 - 30 °
Security algorithms	128-bit AES, HTTPS, SRTP, SSL/TLS
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols	TCP/IP (IPv4), DHCP/ stastic IP, HTTP/ HTTPS, SRTP/TLS, IEEE802.1X, LLDP-MED, VLAN
Current	2 A
Power consumption (max)	30 W
Power consumption (typical)	24 W
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	151.5 mm
Width	234.6 mm
Height	161 mm
Package depth	318 mm
Package width	432 mm
Package height	274 mm
Package weight	5900 g
