Yealink VC110 Administrator's Guide

Administrator’s Guide for Yealink VC110 Video Conferencing Endpoint
268
2. Select the desired value from the pull-down list of Abnormal Call Answering.
3. Click Confirm to accept the change.
Configuring Safe Mode Call
Safe Mode Call feature is used to verify whether the incoming H.323 call is coming from a video
conferencing endpoint.
The Safe Mode Call parameter on the endpoint is described below:
Parameter
Description
Configuration Method
Safe Mode Call
Enables or disables the Safe Mode
Call feature
 Disabled—Answer incoming
H.323 calls directly without
validation.
 Enabled—Verify whether the
incoming H.323 call is coming
from a video conferencing
endpoint. If it is, the VC110
video conferencing endpoint
will answer it. If not, the
incoming call will be rejected.
Default: Enabled
Web User Interface

Yealink VC110 Specifications

General

Digital zoom	4 x
Focus adjustment	Auto
Video codecs	H.264, H.263
Maximum frame rate	30 fps
Supported video modes	720p, 1080p
Video formats supported	H.263, H.264
Supported graphics resolutions	352 x 288, 704 x 576, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Voice codecs	G.711a, G.722, G.722.1, G.722.1C
Line-in	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Pan range	-100 - 100 °
Tilt angle range	-30 - 30 °
Security algorithms	128-bit AES, HTTPS, SRTP, SSL/TLS
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols	TCP/IP (IPv4), DHCP/ stastic IP, HTTP/ HTTPS, SRTP/TLS, IEEE802.1X, LLDP-MED, VLAN
Current	2 A
Power consumption (max)	30 W
Power consumption (typical)	24 W
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	151.5 mm
Width	234.6 mm
Height	161 mm
Package depth	318 mm
Package width	432 mm
Package height	274 mm
Package weight	5900 g
