Yealink VC110 Administrator's Guide

Administrator’s Guide for Yealink VC110 Video Conferencing Endpoint
162
2. Select the desired value from the pull-down list of History Record.
3. Click Confirm to accept the change.
To configure history record via the remote control:
1. Select Menu->Call Features.
2. Check the History Record checkbox.
3. Press the Save soft key to accept the change.
Bandwidth
The endpoint automatically detects the available bandwidth for call connection by default. The
VC110 supports connecting to other devices with different bandwidth. If a device with lower
bandwidth joins a call, the video quality will stay the same or will not reduce a lot. You can
specify the uplink and downlink bandwidths for the endpoint to achieve the best result. Uplink
bandwidth is the max bandwidth of outgoing calls. And downlink bandwidth is the max
bandwidth of incoming calls.
The configurable bandwidths on the endpoint are: 256 kb/s, 384 kb/s, 512 kb/s, 640 kb/s, 768
kb/s, 1024 kb/s, 1280 kb/s, 1500 kb/s, 2000 kb/s, 3000 kb/s, 4000 kb/s. You can configure which
bandwidth is to be used when in the dialing screen. The optional maximum bandwidth in dialing
screen is the uplink bandwidth.
Note
Bandwidth settings parameters on the endpoint are described below:
Parameter
Description
Configuration Method
Uplink Bandwidth
Specifies the maximum transmitting
bandwidth for the endpoint.
Remote Control
Web User Interface
The actual bandwidth depends on the performance of the remote endpoint, and is affected by
the quality of the communication channel.

Yealink VC110 Specifications

General

Digital zoom	4 x
Focus adjustment	Auto
Video codecs	H.264, H.263
Maximum frame rate	30 fps
Supported video modes	720p, 1080p
Video formats supported	H.263, H.264
Supported graphics resolutions	352 x 288, 704 x 576, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Voice codecs	G.711a, G.722, G.722.1, G.722.1C
Line-in	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Pan range	-100 - 100 °
Tilt angle range	-30 - 30 °
Security algorithms	128-bit AES, HTTPS, SRTP, SSL/TLS
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols	TCP/IP (IPv4), DHCP/ stastic IP, HTTP/ HTTPS, SRTP/TLS, IEEE802.1X, LLDP-MED, VLAN
Current	2 A
Power consumption (max)	30 W
Power consumption (typical)	24 W
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	151.5 mm
Width	234.6 mm
Height	161 mm
Package depth	318 mm
Package width	432 mm
Package height	274 mm
Package weight	5900 g
