Yealink VC110 Administrator's Guide

Administrator’s Guide for Yealink VC110 Video Conferencing Endpoint
244
Two-way Video Call with Presentation
In the primary display device, the remote video image is shown in big size, and the local video
image along the right side of the screen is shown in small size.
In the secondary display device, the presentation is shown in full size.
Primary display device Secondary display device
Endpoint Integrated with Control Systems
The Yealink video conferencing endpoints provide an API interface for the third-party control
system. The API commands can be sent to Yealink video conferencing endpoints over LAN or
serial port, to realize controlling the Yealink video conferencing endpoints.
Using the API with a LAN Connection
API commands can be sent to video conferencing endpoint through TCP protocol. The control
system needs to know the IP address and port of the Yealink video conferencing endpoint. For
security, you can configure an authentication password for TCP connection.
LAN Connection parameters are described below.
Parameter
Description
Configuration Method
Current Control
TCP Port
Control TCP port (read-only).
Default: 6024
Web User Interface
Control Security
Enabled
Enables or disables an
authentication password for TCP
connection
Default: Enabled
Web User Interface
Control Security
Password
Configures the authentication
password for TCP connection.
Web User Interface
To configure LAN Connection parameters via web user interface:
1. Click on Security->Security Control.
2. Select the desired value from the pull-down lists of Control Security Enabled.
PC presentation
Local
Far end

Yealink VC110 Specifications

General

Digital zoom	4 x
Focus adjustment	Auto
Video codecs	H.264, H.263
Maximum frame rate	30 fps
Supported video modes	720p, 1080p
Video formats supported	H.263, H.264
Supported graphics resolutions	352 x 288, 704 x 576, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Voice codecs	G.711a, G.722, G.722.1, G.722.1C
Line-in	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Pan range	-100 - 100 °
Tilt angle range	-30 - 30 °
Security algorithms	128-bit AES, HTTPS, SRTP, SSL/TLS
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols	TCP/IP (IPv4), DHCP/ stastic IP, HTTP/ HTTPS, SRTP/TLS, IEEE802.1X, LLDP-MED, VLAN
Current	2 A
Power consumption (max)	30 W
Power consumption (typical)	24 W
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	151.5 mm
Width	234.6 mm
Height	161 mm
Package depth	318 mm
Package width	432 mm
Package height	274 mm
Package weight	5900 g
