Yealink VC110 Administrator's Guide

Administrator’s Guide for Yealink VC110 Video Conferencing Endpoint
38
Mute Indicator LED on the VCM30 video conferencing microphone array
LED Status
Description
Solid red
The VCM30 is muted when the VC110 is during a call.
Flashing red
The VC110 is ringing.
Solid green
The VCM30 is connected to the cable hub within the first 5
seconds.
The VC110 is placing a call.
The VCM30 is unmuted when the VC110 is during a call.
Off
The VCM30 is not connected to the cable hub.
The VCM30 is idle.
User Interfaces
Three are two ways to customize the configurations of your endpoint:
 Web User Interface
 Remote Control
The following describes how to configure the VC110 video conferencing endpoint via the two
methods above.
Detailed operation steps will be introduced in the feature section.
Web User Interface
You can customize your endpoint via web user interface. To access the web user interface, you
need to know the user name and the administrator’s password. The default user name is “admin”
(case-sensitive), and the default password is “0000”. You can also access the web user interface
with user credential, which is disabled by default. For more information on how to enable the
user credential, refer to User Mode on page 249.
The endpoint uses the HTTPS protocol to access the web user interface by default. For more
information on the access protocol for web user interface access, refer to Web Server Type on
page 251.
Log into the web user interface of the endpoint:
1. Enter the IP address (e.g.,192.168.0.10) in the address bar of a web browser on your
computer, and then press the Enter key.
2. Enter the administrator user name and password.
3. Click Login.
After you log into the web user interface successfully, you can click Logout on the top
right corner of the web interface to log out.
Administrator has full permission to access every menu in the web user interface. User can log

Yealink VC110 Specifications

General

Digital zoom	4 x
Focus adjustment	Auto
Video codecs	H.264, H.263
Maximum frame rate	30 fps
Supported video modes	720p, 1080p
Video formats supported	H.263, H.264
Supported graphics resolutions	352 x 288, 704 x 576, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Voice codecs	G.711a, G.722, G.722.1, G.722.1C
Line-in	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Pan range	-100 - 100 °
Tilt angle range	-30 - 30 °
Security algorithms	128-bit AES, HTTPS, SRTP, SSL/TLS
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols	TCP/IP (IPv4), DHCP/ stastic IP, HTTP/ HTTPS, SRTP/TLS, IEEE802.1X, LLDP-MED, VLAN
Current	2 A
Power consumption (max)	30 W
Power consumption (typical)	24 W
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	151.5 mm
Width	234.6 mm
Height	161 mm
Package depth	318 mm
Package width	432 mm
Package height	274 mm
Package weight	5900 g
