Yealink VC110 Administrator's Guide

Administrator’s Guide for Yealink VC110 Video Conferencing Endpoint
200
3. Press the Save soft key to accept the change.
The display device prompts “Reboot now?”.
4. Select OK to reboot the endpoint immediately.
Dual-Stream Protocol
To enhance the process of communicating with others over video, the dual-stream protocol
provides the ability to share content from a computer, such as video clips or documentation.
Both the video and the documentation can be transmitted to the far site simultaneously, thus
meeting the requirements of different conference scenarios, such as training or medical
consultation.
The Yealink video conferencing endpoint supports the standard H.239 protocol and BFCP
(Binary Floor Control Protocol). H.239 protocol is used when sharing content with the far site in
H.323 calls. BFCP protocol is used when sharing content with the far site in SIP calls. Before
enabling the desired protocol, ensure that the protocol is supported and enabled by the far site
you wish to call. If the far site does not support the protocol for sharing content, MCU will
automatically mix the content and camera video, and send them in one channel. For more
information on mix sending, refer to Mix Sending on page 205.
Dual-stream protocol parameters on the endpoint are described below.
Parameter
Description
Configuration Method
H.239
Enables or disables the H.239 protocol for
sharing content. You can configure it for the
StarLeaf Cloud platform or H.323 call
separately.
Default: Enabled
Web User Interface
BFCP
Enables or disables the BFCP protocol for
sharing content. You can configure it for
Zoom/Pexip/BlueJeans/Mind/Custom platform,
SIP account or SIP IP call separately.
Default:
For Zoom/Pexip/BlueJeans/Mind/Custom
platform and SIP IP call, the default value is
Enabled.
For SIP account, the default value is Disabled.
Note: You cannot configure it for the
Yealink/StarLeaf Cloud platform.
Web User Interface
To configure H.239 dual-stream protocol for StarLeaf Cloud platform via web user
interface:
1. Click on Account->VC Platform.

Yealink VC110 Specifications

General

Digital zoom	4 x
Focus adjustment	Auto
Video codecs	H.264, H.263
Maximum frame rate	30 fps
Supported video modes	720p, 1080p
Video formats supported	H.263, H.264
Supported graphics resolutions	352 x 288, 704 x 576, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Voice codecs	G.711a, G.722, G.722.1, G.722.1C
Line-in	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Pan range	-100 - 100 °
Tilt angle range	-30 - 30 °
Security algorithms	128-bit AES, HTTPS, SRTP, SSL/TLS
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols	TCP/IP (IPv4), DHCP/ stastic IP, HTTP/ HTTPS, SRTP/TLS, IEEE802.1X, LLDP-MED, VLAN
Current	2 A
Power consumption (max)	30 W
Power consumption (typical)	24 W
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	151.5 mm
Width	234.6 mm
Height	161 mm
Package depth	318 mm
Package width	432 mm
Package height	274 mm
Package weight	5900 g
