11、REAR COVER COMPONENT 98
CHK
ADJ
NO. PART NO. PART NAME QTY CAUTION
1
1184200-016000 ZT310 PKE buzzer 1
2
1184200-053000 ZT310PKE external single antenna 1
Fig.4 REAR COVER
COMPONENT
Tail skirt taillight component 1
PROCEDURE:
●buzzer
Find the connector of the buzzer ⑴ close to the side cover on the front left side of the rear cover, and press the
card of the white plug to remove the plug.Move the buzzer after back and forth with a hot air gun or hair dryer
with heat.
●PKE antenna
Find the plug of PKE antenna at the front of right rear cover, pull it out and arrange the cable.
The PKE antenna ⑵ is pasted with the double topping and the double topping on the rear cover.Heat it slightly
with a hot air gun, then tear off the double topping and clean up the residue.
The end of the antenna connected to the main beam can be removed from the gap between the frame and the
rear decoration cover.
●The tail light plug
① it is not necessary to pull out the cushion lock plug if the cushion lock is not removed.
② is the tail light plug, need to be pulled out first, convenient back to remove the tail skirt components.
CAUTION:
●When heating, it is forbidden to heat at a fixed position all the time, and it is necessary to move the heating
back and forth.
●Do not pull the cable directly when unplugging the plug.
